Description
VE.Direct port:
- Compatible with:
- Computer (requires VE.Direct to USB cable)
- Apple and Android smartphones, tablets, MacBooks and other devices (requires VE.Direct Bluetooth Dual module)
Configurable features:
- Alarms for low battery voltage and reset
- Settings for battery shutdown and restart
- Dynamic load-dependent disconnection
- Output voltage adjustable between 210V and 245V
- Frequency: 50Hz or 60Hz
- ECO mode on/off and adjustable sensitivity
- Monitoring of input and output voltage, charging and alarms
SinusMAX technology: Phoenix inverters use advanced SinusMAX technology, offering full-load start-up, ideal for equipment requiring high-current start-up.
Reliability and Performance:
- Toroidal transformer design for superior reliability
- Protection against short circuits, overloads and overheating
- Compatible with demanding loads: computers, LED/halogen lamps, power tools
Smart ECO Mode: The inverter automatically switches to standby when the load drops below a preset level and resumes operation when the load increases.
On/Off Remote Control: Remote control option for remote operation, connectable to a two-pin connector.
Automatic Transfer Switch (Filax): Very short transfer time (under 20 ms) to ensure uninterrupted operation of sensitive equipment, such as computers.
Technical Specifications:
-
Dimensions: 86 x 172 x 275 mm
-
Weight: 3.9 kg
-
Power output (25°C): 500VA
-
Rated power (25°C/40°C): 400W / 350W
-
Peak power: 900W
-
Output voltage/frequency: 230VAC ± 3%, 50Hz or 60Hz ± 0.1%
-
Input voltage: 9.2V - 17V
-
Low battery voltage alarm: 10.9V
-
Battery cut-off: 9.3V
-
Battery voltage recovery: 14.0V
-
Maximum efficiency: 90%
-
Power consumption at no load: 6W
-
Protections: short circuit, overload, overtemperature
-
Operating temperature range: -40°C to +65°C (with fan)
-
Maximum humidity: 95% (non-condensing)
-
Certifications: EN-IEC 60335-1, EN-IEC 62109-1, UL 458, EN55014-1, EN 55014-2, IEC 61000-6-1, IEC 61000-6-2, IEC 61000-6-3
