Description
Display screen: 2.4" colour LCD screen
Input voltage range: 230V AC
Output voltage range: 0–60 V
Output voltage adjustment range: 0.01 V
Output current range: 0–6 A
Output power range: 0–360 W
Battery voltage measurement resolution: 0.01 V.
Output voltage accuracy: ±(0.3% + 3 digits).
Output current accuracy: ±(0.5% + 5 digits).
Input voltage accuracy: ±(1% + 5 digits).
Battery voltage measurement accuracy: ±(0.5% + 3 digits).
Operating temperature range: -10~40 °C.
Response time in constant voltage mode: 2 ms (0.1–5 A load).
External sensor temperature detection range: -10~100 °C/0~200 °F.
Temperature detection accuracy: ±3 °C/±6 °F.
Constant current control: ±(0.1% + 3 digits).
Capacity measurement range: 0–9,999.9999 Ah.
Screen brightness adjustment: 0–5 levels, a total of 6 levels.
Energy measurement range: 0–9,999.9999 Ah.
Statistical error of capacity and energy: ±2%.
Voltage drop > 1 V and > 10%.
Warning:
The output must be used in isolation from the input, otherwise the power supply may be damaged.
If you connect an inductive device (motor, etc.), the output current must not exceed 1/3 of the power supply’s rated current.
This limit must not be exceeded, even for short periods.
