DEYE 6kW Single-Phase Hybrid Inverter SUN-6K-SG05LP1-EU-AM2-P

Description

The DEYE SUN-6K-SG05LP1-EU-AM2-P Hybrid Inverter is a reliable single-phase solution specifically designed for residential photovoltaic systems. With a power output of 6 kW, hybrid functionality, and advanced energy management capabilities, this inverter enables the efficient integration of solar power, battery storage, and uninterrupted backup energy supply for household use. It is an excellent choice for homeowners looking to maximize self-consumption, increase energy independence, and reduce reliance on the utility grid.

Model SUN-3.6K-SG05LP1-EU-AM2-P SUN-5K-SG05LP1-EU-AM2-P SUN-6K-SG05LP1-EU-AM2-P SUN-7K-SG05LP1-EU-AM2-P SUN-7.6K-SG05LP1-EU-AM2-P SUN-8K-SG05LP1-EU-AM2-P SUN-10K-SG05LP1-EU-AM2-P
Battery Input Data
Battery Type Lead-acid or Lithium-ion
Battery Voltage Range (V) 40–60
Max. Charging Current (A) 90 120 135 175 190 190 210
Max. Discharge Current (A) 90 120 135 175 190 190 210
Charging Strategy for Li-ion Battery Self-adaptation to BMS
Number of battery inputs 1
PV String Input Data
Max. PV Input Power (W) 7200 10,000 12,000 14000 15200 16,000 20,000
Max PV Input Power (W) 5760 8000 9600 11,200 12160 12,800 16000
Max PV Input Voltage (V) 500
Start-up Voltage (V) 125
MPPT Voltage Range (V) 150–425
Rated PV Input Voltage (V) 370
Maximum operating PV input current (A) 18+18 18+18 18+18 32+32 32+32 32+32 32+32
Maximum Input Short-Circuit Current (A) 27+27 27+27 27+27 48+48 48+48 48+48 48+48
No. of MPP Trackers / Strings per MPPT 2 / 1+1 2 / 1+1 2 / 1+1 2 / 2+2 2 / 2+2 2 / 2+2 2 / 2+2
AC Input/Output Data
Rated AC Input/Output Active Power (W) 3600 5000 6000 7000 7600 8000 10,000
Max AC Apparent Power (VA) 3960 5500 6600 7700 8360 8800 11000
Rated AC Input/Output Current (A) 16.4/15.7 22.7/21.7 27.3/26.1 31.9/30.5 34.5/33.0 36.4/34.8 45.5/43.5
Max AC Input/Output Current (A) 18/17.2 25/23.9 30/28.7 35.0/33.5 38/36.3 40/38.3 50/47.9
Max Continuous AC Passthrough (A) 35 / 40 / 50
Peak Power (off-grid) 2× rated power (10s)
Rated Input/Output Voltage Range (V) 220/230V (0.85Un–1.1Un)
Grid Connection Type L + N + PE
Grid Frequency Range 50Hz (45–55Hz) / 60Hz (55–65Hz)
Power Factor Adjustment Range 0.8 leading – 0.8 lagging
THDi <3%
DC Injection Current <0.5% In
Efficiency
Max Efficiency 97.60%
Euro Efficiency 96.50%
MPPT Efficiency >99%
Equipment Protection
Integrated DC reverse polarity protection, AC output overcurrent protection, thermal protection,
AC Output Overvoltage Protection, AC Output Short Circuit Protection, DC Component Monitoring,
Arc Fault Circuit Interrupter (optional), Anti-islanding Protection, DC Switch,
Insulation Impedance Detection, Residual Current Detection
Surge Protection Level TYPE II (DC), TYPE II (AC)
Interface
Communication RS485 / RS232 / CAN
Monitor Mode GPRS / WiFi / Bluetooth / 4G / LAN (optional)
General Data
Operating Temperature Range -40 to +60°C (>45°C derating)
Ambient Humidity 0–100%
Altitude 2500 m
Noise <30 dB(A)
IP Rating IP65
Inverter Topology Non-isolated
Overvoltage Category OVC II (DC), OVC III (AC)
Cabinet Size (mm) 330 × 580 × 232
Weight (kg) 24.9
Warranty 5 years / 10 years
The warranty period depends on the final installation site of the inverter.
Please refer to the warranty policy for details.
Grid Regulation IEC 61727, IEC 62116, CEI 0-21, EN 50549, NRS 097, RD 140, UNE 217002,
OVE Directive R25, G98, G99, VDE-AR-N 4105
Safety EMC Standards IEC/EN 61000-6-1/2/3/4, IEC/EN 62109-1, IEC/EN 62109-2

✅ Connection to the national grid (EN 50549-1)
✅ Colour display + touchscreen
✅ CAN/RS485 communication port
✅ Parallel function
✅ Generator connection or PV surplus routing
✅ 6 programmable periods for battery charging/discharging
✅ Passive cooling
✅ Operates with or without low-voltage batteries
✅ 9600W input from panels
✅ 6kW output power
✅ WiFi module included, with free app
✅ 10-year warranty

Download the technical data sheet
Download user manual (EN)
Download certificate of conformity
