The V-TAC VT-12040-1 battery is a 10.24kWh energy storage solution designed for residential and small commercial photovoltaic systems. It uses LiFePO4 technology, valued for its stability, long service life, and operational safety.
With a nominal voltage of 51.2V and a capacity of 200Ah, the battery is designed for low-voltage systems. It can store the energy generated during the day for use in the evening, at night, or during periods of reduced photovoltaic production.
The IP65-rated enclosure limits the ingress of dust and water, providing greater flexibility when choosing the installation location. Charging is permitted within a temperature range of 0°C to 60°C.
The declared service life is at least 6,000 cycles at 25°C and 90% depth of discharge. CAN communication enables data exchange with compatible inverters and management of the system’s operating parameters.
Main Features
- Storage capacity: 10.24kWh
- LiFePO4 technology
- Nominal voltage: 51.2V
- Nominal capacity: 200Ah
- IP65 protection
- At least 6,000 cycles at 90% DoD
- Standard charge and discharge current: 90A
- Maximum continuous charge and discharge current: 100A
- CAN communication
- Warranty: 10 years
Benefits
Increased self-consumption: The energy generated by the photovoltaic panels can be stored for periods of reduced production.
Long service life: The LiFePO4 cells provide at least 6,000 cycles under the conditions specified by the manufacturer.
Additional protection: The IP65-rated enclosure protects the equipment against dust and water jets.
Photovoltaic system integration: CAN communication enables connection to compatible inverters.
High available power: A continuous current of up to 100A supports consumers with higher energy requirements.
Recommended Applications
- Residential photovoltaic systems
- Hybrid systems with energy storage
- Increasing the self-consumption rate
- Backup power, depending on the inverter configuration
- Homes, cabins, and off-grid applications
- Small commercial applications
Technical Specifications
| Specification |
Value |
| Manufacturer |
V-TAC |
| Model |
VT-12040-1 |
| Manufacturer SKU |
12766 |
| EAN |
3800170260658 |
| Technology |
LiFePO4 |
| Nominal capacity |
200Ah |
| Nominal voltage |
51.2V |
| Nominal energy |
10.24kWh |
| Standard charge current |
90A |
| Standard discharge current |
90A |
| Maximum continuous charge current |
100A |
| Maximum continuous discharge current |
100A |
| Standard charge voltage |
57.6V |
| Maximum charge voltage |
57.6V |
| End-of-discharge voltage |
43.2V |
| Internal resistance |
16mΩ |
| Communication |
CAN |
| Cycle life |
≥6,000 cycles at 25°C and 90% DoD |
| End-of-life capacity |
70% after ≥6,000 cycles |
| Charging temperature |
0°C to 60°C |
| Discharging temperature |
−20°C to 60°C |
| Protection rating |
IP65 |
| Cell configuration |
16S1P |
| Dimensions |
460 × 265 × 800mm |
| Net weight |
95.8kg |
| Colour stated in the datasheet |
Grey |
| Warranty |
10 years |
Compatibility and Integration
The battery communicates via CAN protocol and must be connected to a hybrid or off-grid inverter compatible with 51.2V low-voltage LiFePO4 batteries.
Compatibility depends on the inverter model, communication protocol, and firmware version. We recommend checking compatibility before purchase.
Installation, configuration, and commissioning must be carried out by qualified personnel in accordance with the manufacturer’s instructions and applicable regulations.
